The Rotork IQ3 Pro is the flagship of the legendary IQ range — the world’s best-selling intelligent electric actuator with over 2 million units installed globally. Featuring a unique absolute encoder, built-in data logger, real-time valve torque signature, and non-intrusive Bluetooth® setting via Rotork Insight2 app, the IQ3 Pro delivers unmatched diagnostics and predictive maintenance capability. Available from 35 Nm to 4,500 Nm with full hazardous area certification (ATEX, IECEx, FM, CSA), it is the preferred choice for modern plants pursuing digital transformation and IIoT integration.
| Parameter | Specification |
|---|---|
| Torque Range | 35 – 4,500 Nm (direct), up to 250,000 Nm with gearbox |
| Power Supply | 110–690 VAC, 24–380 VDC, 3-phase & single-phase |
| Enclosure | IP68 (10 m / 7 days), Explosion-proof Ex db IIC T4/T6 |
| Communication | Pakscan™, Profibus, Modbus, HART, FF, Ethernet |
| Display | Large back-lit LCD with multilingual text |
| Setting Tool | Bluetooth® Insight2 (iOS/Android/Windows) |
| Certification | SIL2/3 capable, ATEX, IECEx, FM, CSA, EAC |
Yes — fully non-intrusive via Bluetooth® Insight2 app.
Yes — records torque, events, vibration, and temperature for 5+ years.
SIL2 standard, SIL3 in redundant configuration.
