The Tissin TS700 is a high-performance yet economical pneumatic valve positioner designed for linear and rotary actuators using standard 3-15 psi (0.2–1.0 bar) input signals. Featuring ±0.5% linearity and hysteresis, low air consumption (less than 5 LPM), and simple external zero/span adjustment, it delivers reliable control without the complexity of digital electronics. With a rugged die-cast aluminum body, IP66 protection, and optional limit switches, the TS700 is the ideal choice for general industries where proven analog technology and minimal maintenance are preferred.
| Parameter | Specification |
|---|---|
| Input Signal | 0.2–1.0 bar (3–15 psi) |
| Supply Pressure | 1.4–7.0 bar (20–100 psi) |
| Stroke | Linear: 10–150 mm; Rotary: 55–100° |
| Linearity | ±0.5% F.S. |
| Hysteresis | ±0.5% F.S. |
| Air Consumption | less than 5 LPM (1.4 bar) |
| Air Capacity | 180 LPM (supply), 350 LPM (exhaust) |
| Enclosure | IP66 |
| Temperature Range | -20°C to +70°C (standard), -40°C option |
| Weight | 2.2 kg |
No — it is a pure pneumatic analog positioner (3-15 psi only).
Yes — easily adjustable to 3-9 psi or 9-15 psi.
less than 5 LPM — extremely economical.
No — fully pneumatic operation.
