The Foxboro SRD960 + Danfoss EV220B Hygienic Edition is a fully sanitary on/off control package combining the stainless steel SRD960 positioner with the 3-A certified EV220B solenoid valve. Designed for CIP/SIP cycles, it features Ra less than 0.8 µm wetted surfaces, FDA-compliant seals, and drainable design. The SRD960 provides HART diagnostics and auto-calibration, while the EV220B offers 150°C steam resistance and 16 bar pressure rating. This pre-validated combo ensures compliance with FDA, EHEDG, and 3-A standards, making it ideal for dairy, brewery, and pharmaceutical clean processes with zero dead-leg installation.
| Parameter | Specification |
|---|---|
| Positioner | Foxboro SRD960-SS (Stainless) |
| Valve | Danfoss EV220B 15-32 Hygienic |
| Input Signal | 4-20 mA HART 7 |
| Cycle Time | less than 150 ms (open/close) |
| Pressure Range | 0–16 bar |
| Temperature Range | -10°C to +150°C (SIP) |
| Flow Capacity | Cv 1.6–8.0 (1/2"–1.25") |
| Enclosure | IP66/67, 316L SS |
| Certifications | 3-A, EHEDG, FDA, USP Class VI |
| Power Supply | 24 VDC loop-powered |
Yes, both valve and positioner meet 3-A 68-00.
Yes, 150°C steam for 60 minutes.
Yes, EPDM/PTFE seals, 316L wetted parts.
Yes, SRD960 records stroke count and time.
Yes, zero dead-leg with weld-in design.
Contact our team for inquiries about the Foxboro SRD960 + Danfoss EV220B Hygienic Edition, pricing, or to schedule a demo:
