The Supmea FSC400 Wall-Mounted Ultrasonic Flowmeter is a cutting-edge, non-intrusive solution for accurate flow measurement in closed pipes carrying clean liquids. Utilizing transit-time ultrasonic technology with clamp-on sensors, it eliminates the need for pipe cutting or process shutdowns, making it ideal for retrofitting existing systems. With high accuracy and a wide pipe size range, the FSC400 supports real-time monitoring via 4-20 mA, RS485, and optional GPRS outputs. Designed for durability in industrial environments, this flowmeter is perfect for water management, HVAC, and chemical processing, offering cost-effective, maintenance-free performance.
| Parameter | Specification |
|---|---|
| Measuring Principle | Transit-Time Ultrasonic |
| Flow Velocity Range | 0.01–30 m/s |
| Accuracy | ±1% of reading |
| Repeatability | ±0.2% of reading |
| Pipe Size Range | DN20–DN6000 (0.8"–236") |
| Medium Temperature | -30°C to +160°C (-22°F to +320°F) |
| Fluid Type | Clean liquids, low conductivity (≥20 μS/cm) |
| Output Signals | 4–20 mA, RS485 (Modbus RTU), Pulse/Frequency, GPRS (optional) |
| Power Supply | 8–36 VDC, 85–265 VAC (optional) |
| Display | LCD with backlight |
| Data Storage | Up to 2000 records |
| Enclosure Rating | IP65 |
| Certifications | CE, RoHS |
The Supmea FSC400 Wall-Mounted Ultrasonic Flowmeter is ideal for non-intrusive flow measurement in various industries:
Clamp-on sensors use ultrasonic waves to detect flow velocity externally, ensuring non-intrusive installation.
It fits pipes as small as DN20 (0.8"), with options up to DN6000 (236").
It works best with clean liquids; for dirty or viscous media, consider Supmea’s other flowmeter models.
4–20 mA, RS485 (Modbus RTU), pulse/frequency, and optional GPRS for remote access.
Up to 20 hours of continuous operation, with AC power options for fixed installations.
For more information about the Supmea FSC400 Wall-Mounted Ultrasonic Flowmeter, pricing, or to request a demo, contact our team:
